Operating Wavelength (nm)

1310 or 1550

1310 and 1550

Bandwidth (nm)

±20

±40

Grade

P

A

P

A

Typical Accessinal Loss (dB)

0.1

0.15

0.1

0.15

Insertion Loss (dB)

≤5.6

≤6.0

≤5.8

≤6.2

PDL (dB)

≤0.2

≤0.25

≤0.25

≤0.3

Uniformity (dB)

≤1.0

≤1.4

≤1.2

≤1.5

Directivity (dB)

≥55

Operating Temperature (℃)

-40~+85

Fiber Type

Corning SMF 28-e

Dimension(Ф×L)

250µm bare fiber

Ф3.0mm×54mm

900µm loose tube

Ф4.0mm×65mm

Remarks:
1 . Measured at room temperature and excludes connector loss.
2 . For devices with connectors insertion loss will be 0.3 dB higher.

A

B

C

D

E

F/G

H/I

J/K

L

Type

Grade

Port

Wave
     Length

Coupling Ratio

Input/Output

Pigtail

Type

Input/Output

Fiber Length

Input/Output

Connector

Package
Type

S
      W

P
 A

103=1x3

303=3x3

13=1310
     nm
15=1550
     nm
35=1310/1550nm

X=Others

0=Even
      X=Others

0=250um Bare Fiber
1=900um loose tube
2=2.0mm loose tube
3=3.0mm loose tube

05=0.5M
……
10=1.0M
……
15=1.5M
……

0=None
FU=FC/UPC
FA=FC/APC
SU=SC/UPC
SA=SC/APC
LU=LC/UPC
LA=LC/APC
ST=ST

X=Others

T8=Φ3.0x54 mm
T9=Φ3.0x60 mm
T11=Ф4.0mm×65mm
P1=90 x 20 x9.5mm ABS Plastic Case
X=Others

* Type:

S -- Singlemode Standard Coupler
W -- Singlemode Wideband Coupler
