Model No: 单模单窗口1×3熔融拉锥耦合器

Single Mode Single Window 1x3 FBT Coupler

Single Mode Single Window 1x3 FBT Coupler，As one of the leading single mode single fusion 1x3 coupler manufacturers and suppliers in China, and equipped with a productive factory, ZG Technology (Shenzhen) Limited can offer you customized and low price single mode single fusion 1x3 coupler made in China. Welcome to visit our website.

minimum order :

1 piece

Supply Ability :

5000piece /

Stock Time :

7Day

Country of Origin :

china

Quantity :

US $10.70 / piece

Buy Now

add to cart

Contact Now

All Products

Subscribe to our Newsletter

Message Content

Country

Phone

Company Name

Name

Single Mode Single Window 1x3 Coupler FBT Coupler，As one of the leading single mode single fusion 1x3 coupler manufacturers and suppliers in China, and equipped with a productive factory, ZG Technology (Shenzhen) Limited can offer you customized and low price single mode single fusion 1x3 coupler made in China. Welcome to visit our website.

Single Mode Single Window 1x3 Coupler FBT Coupler

Applications

Features

Optical fiber test system

Telecommunication system

Luminous power feedback

Low insertion loss

High directivey

Compact size

Extremely good stability and reliability

Single Mode Single Window 1x3 Coupler FBT Coupler

Single Mode Single Window 1x3 Coupler FBT Coupler
Performance Specifications

Coupling ratio		33:33:33
Operating wavelength	nm	1310 / 1550±40
Port numberss		1×3
Grade		P	A
Excess loss	dB	0.2	0.3
Max insertion loss	dB	5.6	6.0
Max polarization indepedent loss	dB	0.25	0.30
Max uniformity	dB	1.2	1.8
Mini return loss	dB	55
Operating temperature	℃	-10～+70
Storage temperature	℃	-40～+85
Dimensions	mm	B=Φ3×60 for bare fiber
Dimensions	mm	L=Φ3.5×70 for 900um loose tube
