Model No: SC PC 0.9
PLC Splitter - Steel Tube-1x16
Product Highlights
Split Input Signal Evenly into 16 Output Ports
≤13.8dB Low Insertion Loss and ≤0.3dB Low Polarization Dependent Loss
1260~1650nm Broad Operating Wavelengths
Compact Housing Fits Racks, Wall-mounted Boxes, Optical Distribution Boxes, etc.
Commonly Found in POL, Datacom, LAN, CATV, LCP, FTTx
Split Input Signal Evenly into 16 Output Ports
≤13.8dB Low Insertion Loss and ≤0.3dB Low Polarization Dependent Loss
1260~1650nm Broad Operating Wavelengths
Compact Housing Fits Racks, Wall-mounted Boxes, Optical Distribution Boxes, etc.
Commonly Found in POL, Datacom, LAN, CATV, LCP, FTTx
Quantity :
0.00
Subscribe to our Newsletter
PLC Splitter - Steel Tube-1:16(PLC Splitter) is a kind of integrated waveguide optical power distribution device based on quartz substrate.
PLC Splitter - Steel Tube-1:16 has the characteristics of small size, wide working wavelength range, high reliability, good spectral uniformity and so on. It is especially used in passive optical network (EPON, GPON, etc.) to connect the local terminal and terminal equipment and realize optical signal shunt. We provide a full range of 1×N and 2×N products, and tailor optical splitters for various occasions.
PLC Splitter - Steel Tube-1:16 is one of the important passive optical devices in optical fiber links.
PLC Splitter - Steel Tube-1:16 has one or more input terminals and several output terminals. The three most important components of the optical fiber array are input, output and chip. The design and assembly of these three components play an important role in the stable and normal operation of the PLC optical shunt.
