Model No: GBIC Duplex Optic Transceiver Module
GBIC Duplex Optic Transceiver Module
The GBIC Duplex Optic Transceiver Module supports dual-directional transmission and can operate in full-duplex mode. It consists of two separate unidirectional transmission channels, each with a red and black light switch for transmitting and receiving data. This type of module can be inserted into standard GBIC slots and is often used in high-speed networks such as Gigabit Ethernet, Fast Ethernet, and Fiber Channel.
Quantity :
0.00
Subscribe to our Newsletter
GBIC Duplex Optic Transceiver Module
The GBIC Duplex Optic Transceiver Module supports dual-directional transmission and can operate in full-duplex mode. It consists of two separate unidirectional transmission channels, each with a red and black light switch for transmitting and receiving data. This type of module can be inserted into standard GBIC slots and is often used in high-speed networks such as Gigabit Ethernet, Fast Ethernet, and Fiber Channel.
GBIC Duplex Optic Transceiver Module
Product Introduction
Features
●Up to 155Mbps/1.25Gbps/2.5Gbps
●Distance up to 20KM/40KM/60KM/80KM
●Extended power supply +3.3/5.0V compatible
●Hot Plug-gable
●Low EMI
●Low power dissipation
●Compliant ROHS6
●Class 1 Laser Product Compliant with the requirements of IEC 60825-1 and IEC 60825-2
●Compliant with Gigabit interface converter (GBIC) Revision 5.5
●Compliant with proposed specifications for IEEE 802.3z/Gigabit Ethernet
Optic Transceiver Module Applications
●Ethernet
●Switch to switch interface
● High-speed I/O for file servers
●Bus extension applications
Features
●Up to 155Mbps/1.25Gbps/2.5Gbps
●Distance up to 20KM/40KM/60KM/80KM
●Extended power supply +3.3/5.0V compatible
●Hot Plug-gable
●Low EMI
●Low power dissipation
●Compliant ROHS6
●Class 1 Laser Product Compliant with the requirements of IEC 60825-1 and IEC 60825-2
●Compliant with Gigabit interface converter (GBIC) Revision 5.5
●Compliant with proposed specifications for IEEE 802.3z/Gigabit Ethernet
Optic Transceiver Module Applications
●Ethernet
●Switch to switch interface
● High-speed I/O for file servers
●Bus extension applications
Product Paramenters
Product Number | Data Rate | Wavelength (nm) | Transmission Distance | Connector | Laser (Tx) | Detector (RX) | Datasheet Download |
FPSG311MS-40 | 155M | 1310nm | 40KM | SC | FP | PIN | Datasheet |
FPSG551MS-80 | 155M | 1550nm | 80KM | SC | DFB | PIN | Datasheet |
FPMG851GS-05 | 1.25G | 850nm | 550M | SC | VCSEL | PIN | Datasheet |
FPSG311GS-20 | 1.25G | 1310nm | 20KM | SC | FP | PIN | Datasheet |
FPSG551GS-80 | 1.25G | 1550nm | 80KM | SC | DFB | PIN | Datasheet |
FPSG312GS-20 | 2.5G | 1310nm | 20KM | SC | DFB | PIN | Datasheet |
FPSG552GS-20 | 2.5G | 1550nm | 20KM | SC | DFB | PIN | Datasheet |
FPSG552GS-40 | 2.5G | 1550nm | 40KM | SC | DFB | PIN | Datasheet |
