Model No: 10G SFP DWDM Optic Transceiver Module
10G DWDM SFP 80KM Fiber Optic Transceiver Module LC Port
The 10G SFP DWDM Optic Transceiver Module is an optical transmission module used in data centers, enterprise networks, and telecommunications networks, supporting a data transfer rate of 10Gbps. It uses a Small Form-Factor Pluggable (SFP) packaging form with bi-directional transmission capabilities. The module employs Dense Wavelength Division Multiplexing (DWDM) technology, enabling multiple signals to be transmitted over a single fiber, resulting in increased bandwidth usage.
Quantity :
0.00
Subscribe to our Newsletter
10G DWDM SFP 80KM Fiber Optic Transceiver Module LC Port
The 10G SFP DWDM Optic Transceiver Module is an optical transmission module used in data centers, enterprise networks, and telecommunications networks, supporting a data transfer rate of 10Gbps. It uses a Small Form-Factor Pluggable (SFP) packaging form with bi-directional transmission capabilities. The module employs Dense Wavelength Division Multiplexing (DWDM) technology, enabling multiple signals to be transmitted over a single fiber, resulting in increased bandwidth usage.
10G SFP DWDM Optic Transceiver Module
Product Introduction
Features
●Supports 9.95 to 10.3Gb/s bitrates
●DWDM Cooled EML Laser
●APD Receiver up to 80KM transmission
●PIN Receiver up to 40KM transmission
●Single 3. 3V Power supply
●Duplex LC Connector Interface
●C17-C61 100G Grid Channels
●Hot Pluggable,Metal enclosure, for Lower EMI
●Case temperature range: 0℃ to 70℃.
●Compliant with SFP MSA Specification
●Digital diagnostic monitor interface
●Compatible with SFF-8472
10G SFP DWDM Optic Transceiver Module
Product Introduction
Features
●Supports 9.95 to 10.3Gb/s bitrates
●DWDM Cooled EML Laser
●APD Receiver up to 80KM transmission
●PIN Receiver up to 40KM transmission
●Single 3. 3V Power supply
●Duplex LC Connector Interface
●C17-C61 100G Grid Channels
●Hot Pluggable,Metal enclosure, for Lower EMI
●Case temperature range: 0℃ to 70℃.
●Compliant with SFP MSA Specification
●Digital diagnostic monitor interface
●Compatible with SFF-8472
10G SFP DWDM Optic Transceiver Module
Applications
●DWDM Application
●Point-to-Point networking
●SONET Networks
Product Number | Data Rate | Wavelength (nm) | Transmission Distance | Connector | Laser (Tx) | Detector (RX) | Datasheet Download |
FPDPPXX10GL-40D | 10G | ITU-GRID | 40KM | LC | EML | PIN | Datasheet |
C17-C61 | |||||||
FPDPPXX10GL-80D | 10G | ITU-GRID | 80KM | LC | EML | APD | Datasheet |
