Model No: 1x2 Multimode Mechanical Fiber Optic Switch
1x2 MMF Optical Switches Latched or Non latched type
As one of the leading 1x2 multimode mechanical fiberoptic switch manufacturers and suppliers in China, and equipped with a productive factory, ZG Technology (Shenzhen) Limited can offer you customized and low-price 1x2 multimode mechanical fiberoptic switch made in China. Welcome to visit our website.
Quantity :
0.00
Subscribe to our Newsletter
Mechanical Optical Switch 1x2 MMF Optical Switches Latched or Non-latched type
1x2 MMF Optical Switches
Features | Applications |
Unmatched Low Cost Low Insertion Loss 2 Coils Latching / No Latching High Channel Isolation Highly Stable and Reliable Epoxy-Free Optical Path | Optical Signal Routing Optical Network Protection/Restoration Configurable Optical Add/Drop Transmitter and Receiver Protection Network Test Systems Instrumentation |
1x2 MMF Optical Switches
Fiber Optic Switch Ordering Information
MMS | Operating Wavelength | Port | Grade | Fiber Type | Pigtail Type | In/Out Connector |
13=1310±40nm 85=850 ±40nm 83=850/1310nm | 0102=1x2 | P = P Grade A = A Grade | 1 = 50/125 multi-mode 2 = 62.5/125 multi-mode | 1=Bare fiber 2=900um Jacket | 0=None 1=FC/APC 2=FC/PC 3=SC/APC 4=SC/PC 5=ST 6=LC |
