Model No: 1 x 8光纤分路器

1 x 8 PLC Fiber Splitter, Mini Module, 900μm, SC/APC, Singlemode

Product Highlights

Split Input Signal Evenly into 8 Output Ports
≤10.5dB Low Insertion Loss and ≤0.2dB Low Polarization Dependent Loss
Fully Passive Optical Branching Device
Compact Housing Fits Racks, Wall-mounted Boxes, Optical Distribution Boxes, etc.
1260~1650nm Broad Operating Wavelengths
G.657A1 Bend Insensitive Fibers for Low Bending Loss
Commonly Found in POL, Datacom, LAN, CATV, LCP, FTTx

Quantity :

0.00

Buy Now

add to cart

Contact Now

All Products

Subscribe to our Newsletter

Message Content

Country

Phone

Company Name

Name

PLC Splitter - Steel Tube-1:8(PLC Splitter) is a kind of integrated waveguide optical power distribution device based on quartz substrate.

PLC Splitter - Steel Tube-1:8 has the characteristics of small size, wide working wavelength range, high reliability, good spectral uniformity and so on. It is especially used in passive optical network (EPON, GPON, etc.) to connect the local terminal and terminal equipment and realize optical signal shunt. We provide a full range of 1×N and 2×N products, and tailor optical splitters for various occasions.

PLC Splitter - Steel Tube-1:8 is one of the important passive optical devices in optical fiber links.

PLC Splitter - Steel Tube-1:8 has one or more input terminals and several output terminals. The three most important components of the optical fiber array are input, output and chip. The design and assembly of these three components play an important role in the stable and normal operation of the PLC optical shunt.
