Model No: SFP BIDI Optic Transceiver Module
SFP BIDI Module 1.25G BIDI 80km LC DDM Optical Transceiver SMF SFP module
The SFP BIDI Optic Transceiver Module is a small form-factor optical transceiver that utilizes single-channel bidirectional (BIDI) optical transmission technology. It has high-speed and long-distance transmission capabilities, allowing bidirectional transmission over a single fiber optic cable, and also supports fiber optic multiplexing, extending the signal transmission distance to a greater range.
Quantity :
0.00
Subscribe to our Newsletter
SFP BIDI Module 1.25G BIDI 80km LC DDM Optical Transceiver SMF SFP module
The SFP BIDI Optic Transceiver Module is a small form-factor optical transceiver that utilizes single-channel bidirectional (BIDI) optical transmission technology. It has high-speed and long-distance transmission capabilities, allowing bidirectional transmission over a single fiber optic cable, and also supports fiber optic multiplexing, extending the signal transmission distance to a greater range.
SFP BIDI Optic Transceiver Module
Product Introduction
Features
●Operating data rate up to 155M/1.25G/2.5G
●Tx1310nm/Rx1550nm&Tx1550nm/Rx1310nm;TX1310nm/RX1490nm&
TX1490nm/RX1310nm;Tx1490nm/Rx1550nm&Tx1550nm/Rx1490nm
●Single 3. 3V Power supply and TTL Logic Interface
●Simplex SC/ LC Connector Interface,DDM optional
●Hot Pluggable,Metal enclosure, for Lower EMI
●Operating Case Temperature:
Standard: 0℃~+70℃ ; Industrial:-40℃~+85℃
●Compliant with MSA SFP Specification
●Digital Diagnostic Monitor Function Compatible with SFF-8472 and DDM optional
●ROHS6 Compliant
SFP BIDI Optic Transceiver Module
Applications
●Gigabit Ethernet
●WDM Gigabit Ethernet Links
●Xdsl Applications
●Metro Edge Switching
Applications
●Gigabit Ethernet
●WDM Gigabit Ethernet Links
●Xdsl Applications
●Metro Edge Switching
Product Specification
ProductNumber | Data Rate | Wavelength (nm) | Transmission Distance | Connector | Laser (Tx) | Detector (RX) | Datasheet Download |
FPBP351GS(L)-3 | 1.25G | Tx1310 | 3KM | SC(LC) | FP | PIN | Datasheet |
Rx1550 | |||||||
FPBP351GS(L)-3 | 1.25G | Tx1550 | 3KM | SC(LC) | FP | PIN | Datasheet |
Rx1310 | |||||||
FPBP351GS(L)-20 | 1.25G | Tx1310 | 20KM | SC(LC) | FP | PIN | Datasheet |
Rx1550 | |||||||
FPBP531GS(L)-20 | 1.25G | Tx1550 | 20KM | SC(LC) | DFB | PIN | Datasheet |
Rx1310 | |||||||
FPBP451GS(L)-80 | 1.25G | Tx1490 | 80KM | SC(LC) | DFB | PIN | Datasheet |
Rx1550 | |||||||
FPBP541GS(L)-80 | 1.25G | Tx1550 | 80KM | SC(LC) | DFB | PIN | Datasheet |
Rx1490 | |||||||
FPBP451GS(L)-120 | 1.25G | Tx1490 | 120KM | SC(LC) | DFB | APD | Datasheet |
Rx1550 | |||||||
FPBP541GS(L)-120 | 1.25G | Tx1550 | 120KM | SC(LC) | DFB | APD | Datasheet |
Rx1490 | |||||||
FPBP352GS(L)-20 | 2.5G | Tx1310 | 20KM | SC(LC) | DFB | PIN | Datasheet |
Rx1550 | |||||||
FPBP532GS(L)-20 | 2.5G | Tx1550 | 20KM | SC(LC) | DFB | PIN | Datasheet |
Rx1310 | |||||||
FPBP452GS(L)-80 | 2.5G | Tx1490 | 80KM | SC(LC) | DFB | APD | Datasheet |
Rx1550 | |||||||
FPBP542GS(L)-80 | 2.5G | Tx1490 | 80KM | SC(LC) | DFB | APD | Datasheet |
